Description
Item specifications
| Condition: | New original packaging |
| Brand: | Leadshine |
| Model: | DMA860H |
| Supply voltage: | 18-80VAC / 24 – 110 VDC |
| Isolation resistance: | 500 MO |
| Output current: | 1.8A to 7.2A p-p (5.1A max. rms) |
| Logic signal current: | 7 to 16 mA |
| Pulse input frequency: | 0 – 300 KHz |
| Cooling type: | Electric fan |
| Ambient temperature: | 0-35 ?C |
| Manufacture: | China |
| Application: | 2 / 4 phases stepper motor Nema 17 – 43 |
| Warranty: | 30 Days |
